Driving Type:4x2
Horse Power:95HP / 116HP / 140HP
Transmission:WLY6T, 6F & 1R
Loading Capacity:5T / 8T / 10T / 12T
Chassis Model |
ZZ1127G4715C1 |
Driving Type |
LHD (RHD is optional) |
Cabin |
2080 Single and half, with one berth, two seats and A/C |
Engine |
YC4E140, 140HP |
Transmission |
WLY6T51, 6F & 2R with PTO |
Front Axle |
3600 KGS |
Rear Axle |
8200 KGS |
Suspension |
9/12+9 |
Tyres |
8.25R20 tyres, plus one spare tyre |
Working Height |
22000mm |
Max Lifting |
1000 KGS |
Working Arm |
Three arms, Hydraulic Cylinder |
